CBM » Casing » AZZA CASE » GENESIS 9000


Model Name Genesis 9000W
Model Number CSAZ-9000W
Type ATX Full Tower
Color White/White(inside chassis)
Material 0.8mm SECC
Side Panel Window Yes
With Power Supply No
CPU Cooler Compatibility up to 200mm
Motherboard Compatibility XL-ATX,E-ATX, Full ATX, Micro ATX
Power Supply Locations Rear Bottom or Front Bottom, Supports Dual-Power Supply
External 5.25" Drive Bay 9
Internal 3.5 Drive Bays 5+1(up to 9)
Easy Swap 2.5" SSD Slot 2 (up to 5)
Easy Swap 3.5"  HDD Slot 2(up to 5)
Expansion Slots 9
Front Ports
Front Ports 2x USB 3.0, 2xUSB 2.0, e-SATA, HD Audio, Mic
Cooling System
230mm Fan 2x230mm  Silent Fan (24DBA) on The Top w/Fan Speed Control
140mm Fan 2x140mm Silent Fan (19DBA) at Bottom w/Fan Speed Control
120mm Fan 1x120mm Fan in Rear, 2x120mm on the Side for HDD
Physical Spec
Dimensions (HxWxD) 25.1"x9.8"x23.2" (640mmx250mmx590mm)
Weight 36 lbs
Optimum Cooling for GPU.CPU Reversible motherboard tray can be rotated 180 degrees to
orient graphics cards at the top, next to the top fan to
enhance the efficiency of heat dissipation.
Ideal Aerodynamic Airflow

An ideal vertical airflow is generated to offer exceptional
system cooling: with the power supply installed at the front
bottom, 2x140mm stock fans located at the bottom blast cool
air upward with the heat exhausted via the 2x230mm top fan.

Exceptional Cooling System
Total 7 fans
2x230mm fans located on the top to exhaust hot air.
2x140mm fans located at the bottom to take in cool air.
2x120mm fan located on side panel for cooling HDD.
1x120mm fan locate in the rear to exhaust the hot air.
Easy Swap Slots for 3.5" HDD and 2.5" SSD
2x Easy Swap HDD tray (up to 5) for easy, tool-less assembly of HDD.
Maximum Capacity Water
Top Mount Radiator: supports up to 480mm radiator.
Bottom Mount Radiator: support up to 240mm radiator.
Supports Lengthiest of Graphics Cards Accommodates graphics cards up to 400mm in length.
USB 3.0 Ready 2xUSB 3.0, 2xUSB 2.0, 1xeSATA
Supports Dual-Power Supply Power supply can be located at either front or rear bottom.
Also supports dual-power supply.
Maximum Compatibility

Accommodates XL-ATX, E-ATX, Full ATX, Micro ATX and
all Nvdia and ATI graphics cards up to 400mm in length.
Supports all water cooling radiator systems up to 480mm.

Easy CPU Cooler Installation
A cut-out hole for easy CPU cooler installation -- no need to
remove motherboard.
